Note: When LAN IP or bridge mode status is changed, the system will reboot! If bridge
mode is chosen, static LAN configuration will be disabled automatically.
8.3.2.3 Qos & VLAN Config
The phone supports 802.1Q/P protocol and DiffServ configuration. Use of a Virtual LAN (VLAN) allows
voice and data traffic to be separated.
Chart 1 shows a network switch with no VLAN. Any broadcast frames will be transmitted to all other ports.
For example, and frames broadcast from Port 1 will be sent to Ports 2, 3, and 4.
