Field Name
Explanation
Enable LLDP
Enable or Disable Link Layer Discovery Protocol (LLDP)
Packet Interval
The time interval for sending LLDP Packets
Enable Learning Function
Enables the telephone to synchronize its VLAN data with the
Network Switch. The telephone will automatically synchronize
DSCP, 802.1p, and VLAN ID values even if these values differ
from those provided by the LLDP server.
Enable DSCP
Enable or Disable Differentiated Services Code Point (DSCP)
SIP DSCP Specify the value of the SIP DSCP in decimal
Audio DSCP Specify the value of the Audio DSCP in decimal
Enable WAN Port VLAN Enable or Disable WAN Port VLAN
WAN Port VLAN ID Specify the value of the WAN Port VLAN ID. Range is
0-4095
SIP 802.1P Priority
Specify the value of the voice 802.1p priority. Range is 0-7
Audio 802.1P Priority Specify the value of the signal 8021.p priority. Range is 0-7
LAN Port VLAN Mode Follow WAN: LAN Port ID is same as WAN ID
