Fanvil F52 - WEB DIAL Function

Fanvil Technology Co., Ltd
HQ Add: Level 3, Block A, Gaoxinqi Building, Anhua Industrial Park, Qianjin 1 Road, 35th District, Bao'An, Shenzhen, 518101 P.R. China
Tel: +86-755-2640-2199 Fax: +86-755-2640-2618 Email: fanvil@fanvil.com www.fanvil.com Beijing Tel:+86-10-5753-6809
Suzhou Tel: +86-512-6592-0605 SEA Tel: +60-3-203-50737
- 70 -
either via XML or LDAP.
TFTP example for remote xml mode: Set the Phonebook Name as Fanvil - Server URL is
tftp://192.168.1.3/admin/phonebook/index.xml.
Remote Phonebook Settings
Phonebook Name Phonebook name displayed on the phone.
Server URL
Server url of the remote phonebook.
SIP Line SIP line for the remote phonebook.
User/password Authentication username and password.
LDAP Settings
Display Title
The name displayed on the LCD.
Version LDAP protocol version; supports 3 as default.
Server Address
LDAP server address.
Server Port LDAP server port.
Authentication depending on the server’s authentication mode. There are
