Fargo DTC4500e User Manual

DTC4500e_User Guide_EN, PLT-01669, Rev. 1.1
Page 4 April 2014
4.1.4 Diagnostics .................................................................................................................................... 28
4.1.5 Test Print ....................................................................................................................................... 28
4.1.6 Toolbox .......................................................................................................................................... 28
4.2 Configuration (Toolbox) ........................................................................................................................ 29
4.2.1 Set Language ................................................................................................................................ 29
4.3 Calibrate Laminator (Toolbox) .............................................................................................................. 30
4.4 Calibrate Ribbon (Toolbox) ................................................................................................................... 31
4.5 Clean Printer (Toolbox) ........................................................................................................................ 32
4.5.1 Safety Messages (Review Carefully) ............................................................................................ 33
4.5.2 Cleaning Kit ................................................................................................................................... 35
4.5.3 Printhead Cleaning ........................................................................................................................ 36
4.5.4 Cleaning the Platen and the Card Feed Rollers ............................................................................ 36
4.5.5 Cleaning the Printer’s Exterior ....................................................................................................... 38
4.6 Advanced Settings (Toolbox) ............................................................................................................... 39
4.6.1 Overview of Advanced Settings .................................................................................................... 40
4.7 Device Options Tab .............................................................................................................................. 44
4.7.1 Supplies ......................................................................................................................................... 45
4.7.1.1 Ribbon Type ........................................................................................................................... 45
4.7.2 Dual Sided ..................................................................................................................................... 46
4.7.2.1 Print Both Sides ..................................................................................................................... 46
4.7.2.2 Split 1 Set of Ribbon Panels .................................................................................................. 46
4.7.2.3 Print Back Image on Front of Card ........................................................................................ 46
4.7.2.4 Print Back Side Only .............................................................................................................. 46
4.7.3 Options .......................................................................................................................................... 46
4.7.3.1 Rotate Front 180 Degrees...................................................................................................... 46
4.7.3.2 Rotate Back 180 Degrees ...................................................................................................... 46
4.7.3.3 Disable Printing ...................................................................................................................... 46
4.7.3.4 Write Only............................................................................................................................... 47
4.7.3.5 Encrypt Job Data .................................................................................................................... 47
4.7.4 Fluorescent Panels ........................................................................................................................ 48
4.7.4.1 Selecting the Fluorescent Panel Ribbon Type ....................................................................... 48
4.7.4.2 Creating a Custom Fluorescent Image using the YMCFKO Ribbon ..................................... 49
4.7.4.3 Configuring Fluorescent Data using the Application .............................................................. 49
4.8 Image Color Tab ................................................................................................................................... 51

Fargo DTC4500e Specifications

General

Print Technology	Dye-Sublimation / Resin Thermal Transfer
Resolution	300 dpi
Supported Card Sizes	CR-80, CR-79 adhesive back
Memory	32 MB RAM
Operating System Supported	Windows 7, 8, 10, Server 2008, 2012, 2016
Print Speed	Up to 225 cards per hour (YMCKO)
Card Capacity	100 cards
Connectivity	USB 2.0, Ethernet
Print Capability	Single-sided or dual-sided printing
Power Requirements	100-240V AC, 50/60Hz
Operating Humidity	20-80% RH
Card Thickness	9 mil to 40 mil
Operating Temperature	65° F to 90° F / 18° C to 32° C
