Fargo DTC4500e User Manual

DTC4500e_User Guide_EN, PLT-01669, Rev. 1.1
April 2014 Page 5
4.8.1 Image Quality ................................................................................................................................ 52
4.8.1.1 Color Matching ....................................................................................................................... 52
4.8.1.2 Resin Dither ........................................................................................................................... 52
4.8.2 Heat ............................................................................................................................................... 52
4.8.2.1 Dye-Sub Intensity (YMC) ....................................................................................................... 52
4.8.2.2 Resin Heat, Front (K) ............................................................................................................. 52
4.8.2.3 Resin Heat, Back (K) .............................................................................................................. 53
4.8.2.4 Overlay Heat (O) .................................................................................................................... 53
4.8.3 Default ........................................................................................................................................... 53
4.8.4 Advanced Settings ........................................................................................................................ 54
4.8.4.1 Image Quality ......................................................................................................................... 54
4.8.4.2 Balance .................................................................................................................................. 55
4.8.4.3 Default .................................................................................................................................... 55
4.9 Image Calibrate Tab ............................................................................................................................. 56
4.9.1 Vertical ........................................................................................................................................... 56
4.9.2 Horizontal ...................................................................................................................................... 56
4.10 Magnetic Encoding Tab .................................................................................................................... 57
4.10.1 Encoding Options .......................................................................................................................... 57
4.10.1.1 ISO Encoding ......................................................................................................................... 58
4.10.1.2 Custom Encoding or Raw Binary Encoding Mode ................................................................. 59
4.10.2 Magnetic Track Options ................................................................................................................ 60
4.10.2.1 Reviewing the ISO Track Locations ....................................................................................... 60
4.10.2.2 Reviewing the Sample String ................................................................................................. 61
4.10.2.3 Sending the Track Data ......................................................................................................... 61
4.11 Lamination Tab ................................................................................................................................. 63
4.11.1 Lamination Position ....................................................................................................................... 63
4.11.2 Lamination Speed ......................................................................................................................... 63
4.11.3 Lamination Side ............................................................................................................................. 64
4.11.4 Lamination Type ............................................................................................................................ 64
4.11.5 Automatically detect installed Laminate for every print job. .......................................................... 64
4.12 Overlay / Print Area Tab ................................................................................................................... 65
4.12.1 Defining an Overlay or Print Area.................................................................................................. 65
4.12.2 Deleting a Defined Area ................................................................................................................ 66
4.12.3 Overlay / Print Area ....................................................................................................................... 66

Fargo DTC4500e Specifications

General

Print Technology	Dye-Sublimation / Resin Thermal Transfer
Resolution	300 dpi
Supported Card Sizes	CR-80, CR-79 adhesive back
Memory	32 MB RAM
Operating System Supported	Windows 7, 8, 10, Server 2008, 2012, 2016
Print Speed	Up to 225 cards per hour (YMCKO)
Card Capacity	100 cards
Connectivity	USB 2.0, Ethernet
Print Capability	Single-sided or dual-sided printing
Power Requirements	100-240V AC, 50/60Hz
Operating Humidity	20-80% RH
Card Thickness	9 mil to 40 mil
Operating Temperature	65° F to 90° F / 18° C to 32° C
