Farr HD8625 - Page 118

6.2
hD8625 8-
5
/
8
” 35K Tong
Technical Manual
Torque MeasureMenT
Item Type Description Qty Part Number
Assembly
36”Arm-40KTorqueGauge/CompressionLoadCellAssembly 1 10-0016C
1 Part
36”Arm40,000Ft.-Lbs.TorqueGauge 1 10-0016G
2 Part
CompressionLoadCell 1 10-0008C
3 Part
HydraulicHose 1 02-0069
4 Part
TorqueGaugeFlange 1 997-D7-5
5 Part
1”TensionLoadCellShackle 1 02-9134
THE TORQUE GAUGE USED IS FULLY DEPENDANT UPON THE ARM LENGTH AND
TORQUE RANGE OF THE EQUIPMENT IN USE. THE PART NUMBERS LISTED IN THE
FOLLOWING TABLE ARE CORRECT FOR ACCURATELY MEASURING TORQUE USING
THE EQUIPMENT FOR WHICH THIS MANUAL IS SUPPLIED.
BASIC TORQUE MEASUREMENT (Continued:)
Theimagesontheprecedingpageareforillustrationpurposesonlyandmaynotaccuratelyrepresentthetorquegaugeandloadcellthat
havebeensuppliedwithyourequipment.Pleasenotethatthepartslistedinthefollowingtablearecorrectforaccuratetorquemeasure-
mentwhileusingtheequipmentforwhichthismanualissupplied.
