IllustratIon 3.D.8: sHIfter sHaft luBrICatIon
8. Shifting Shaft
Applygreasetotheshiftingshaftandtopshiftingshaftbushing.Theshaftandshiftingyokecanbeaccessedthroughthecoverplate
onthesideofthetong.
9. Door Lubrication
Applygreasetothe doorlatchadjustmentcamthrough thegreasefittinglocated inthe topof the adjustmentcamshaft. Apply
greasetothecontactsurfacesofthesafetydoorswitchplunger.
IllustratIon 3.D.9: tong Door luBrICatIon PoInts
MainTenance
Access shifter components
through this panel
Lubricate safety door switch
plunger contact area.
Lubricate door latch cam
through grease fitting.
