Farr HD8625 - Page 57

Technical Manual
hD8625 8-
5
/
8
” 35K Tong
3.15
34. Re-installsupportrollershaftscontinued:
ii) Securethebottomsofthesupportrollershaftswith1”narrowflatwashersand1”UNSthinnylocknuts.InstalltheRHfrontleg
mountweldment(PN101-0163)andtheLHfrontlegmountweldment(PN101-0162)onthetothesupportrollershaftsusing1”
UNSthinnylocknutsandtwo3/8”UNCx1-3/4”hexboltsandlockwashersperweldment(seeIllustration3.H.5).ASSEMBLY
NOTE:
Donotuseflatwasherswheninstallingthe1”UNSnutontheshaftcoincidentalwiththelegweldments.
IllustratIon 3.H.4: tong assemBly - suPPort rollers (seCurIng leg mounts)
IllustratIon 3.H.5: tong assemBly - front leg InstallatIon
Assembly Procedures (continued...):
34. Re-installsupportrollershafts:
i) Installallsupportrollershafts(PN101-3939)thatareNOTcoincidentalwiththebrakebandlugweldmentsasshowninillustra-
tion3.H.4(seventotal).Ensurea1-1/8”narrowflatwasherisinstalledonthesupportrollershaftbeforeinsertingthroughthe
topbodyplateandsupportroller assemblies.Donotinstall thedoorpivotroller atthistime. ASSEMBLY NOTE:Theshafts
coincidentalwiththefrontlegweldmentsareshowncircledinred.
MainTenance
