A Technical appendix
74 Festo – GDCP-CMMP-M0-HW-EN – 1511c – English
Resolver connection [X2A]
Resolver connection
Values Meaning
S1
S3
Input voltage
1)
[V] 3.5 COSINE+
COSINE-
Input frequency [kHz] 5 … 10
Internal resistance R
i
[kΩ]  5
S2
S4
Input voltage
1)
[V] 3.5 SINE+
SINE-
Input frequency [kHz] 5 … 10
Internal resistance R
i
[kΩ]  5
R1 Voltage
1)
[V] 7 Carrier signal
Frequency [kHz) 5 … 10
Output current
1)
[mA] I
A
 150
R2 GND
MT+
MT-
Voltage [V] + 3.3 Motor temperature sensor,
N/C contact, PTC, KTY…
Reference potential for temperature
sensor
Internal resistance R
i
[kΩ] 2
1) Rms value
Tab. A.18 Technical data: Resolver [X2A]
Parameter Values
Transmission ratio 0.5
Carrier frequency [kHz] 5 … 10
Excitation voltage
1)
[V] 7, short circuit proof
Excitation impedance (at
10 kHz)
[Ω]  (20 + j20)
Stator impedance [Ω]  (500 + j1000)
1) Rms value
Tab. A.19 Technical data: Resolver [X2A]
Parameter Values
Resolution [Bit] 16
Signal detection time delay [μs]  200
Speed resolution [min
-1
] approx. 4
Absolute accuracy of angle ac
quisition
[']  5
max. speed [min
-1
] 16000
Tab. A.20 Technical data: Resolver evaluation [X2A]
