Festo CP Series User Manual

PLEASE NOTE
If there are several systems with ducted exhaust
air, use non-return valves in the common exhaust
tubing, in order to avoid impairment of function
as a result of back pressures.
1
2
3
4
5
6
CP terminal 1
Common 3/5
Central 82/84
Central 3/5
CP terminal 2
Common 82/84
Fig. 3/4: Common tubing with non-return valves
1
2 3 4
5
2
6
6
2
3. Installation
CPV... 9802 3-9
