Festo CP Series User Manual

PLEASE NOTE
In the case of CP terminals with two pressure zones
and auxiliary pilot air taken internally on the right-
hand side, the pressure on the right-hand side must
be between 3 bar and 8 bar.
PLEASE NOTE
In the case of CP terminals with ducted supply air,
connections 11 and 12/14 must be sealed with blind
plugs.
Vacuum/low pressure operation
The CP terminal can be operated with vacuum or low
pressure (< 3 bar), providing regulated auxiliary pilot air
is supplied separately (summary see "Conversion from
internal to external auxiliary pilot air").
3. Installation
3-10 CPV... 9802
