Festo SOPA - Setting the Allocation of the Switching Output at Pin 4 (EDIT Mode); Setting Security Code (EDIT Mode); Replicating Parameters (EDIT Mode)

4. Press the Edit button to confirm the set value.
Ä
The next adjustable parameter is shown.
8.11 Setting the allocation of the switching output at Pin 4 (EDIT mode)
Requirement: EDIT mode is active.
1. Select the Special menu [Spec] with the A or B pushbutton.
Ä
[Spec] flashes.
2. Press the Edit button repeatedly until [P4-] flashes.
3. Select parameter with A or B pushbutton.
– A = OutA = additional switching point for distance monitoring
– c = OutC = supply pressure monitoring
4. Press the Edit button to confirm the set value.
Ä
The next adjustable parameter is shown.
8.12 Setting security code (EDIT mode)
If you forget the security code, the SOPA must be reset to its factory settings
è 10.2 Restoring Factory Settings (Restore).
Requirement: EDIT mode is active.
1. Select the Special menu [Spec] with the A or B pushbutton.
2. Press the Edit button repeatedly until [Lock] flashes.
3. Select with the A or B pushbutton between inactive security code (OFF) or maximum 4-digit secur-
ity code.
4. Press the Edit button to confirm the set value.
Ä
RUN mode is active.
8.13 Replicating parameters (EDIT mode)
Requirements: EDIT mode is active.
1. Select the Special menu [Spec] with the A or B pushbutton.
Ä
[Spec] flashes.
2. Press the Edit button repeatedly until [rP.] flashes.
3. Select parameter [rP.On] with the A or B pushbutton.
4. Press the Edit button.
Ä
[rP.rd] is displayed.
5. Press the A or B pushbutton to activate the transfer.
Ä
– [rP.rn] is displayed.
– All parameters are transferred from the master sensor to the device sensor.
– [rP.rn] is displayed on completion of the transfer. [rP.Co] or [rP.Id] is displayed in case of
error è 12.1 Error messages.
6. To end the replication function, press the Edit button.
Ä
RUN mode is active.
Commissioning
32 Festo — SOPA — 2020-04
