9.8.2 Block parameterisation for Distance monitoring SSC2 (OutB)
Index Subindex Name
1 Set point SP1(SP)0x003E
2 Set point SP2
2 Switch point mode0x003F
3 Hysteresis (HY)
Tab. 30 Block of coherent OutB parameters
9.8.3 Block parameterisation for Supply pressure monitoringSSC3 (OutC)
Index Subindex Name
1 Set point SP1 (SP.Min)0x4000
2 Set point SP2(SP.Max)
2 Switch point mode0x4001
3 Hysteresis (HY)
Tab. 31 Block of coherent OutC parameters
9.8.4 Block parameterisation for analogue output
Index Subindex Name
0x016A 0 Analog output scaling start distance value
0x016B 0 Analog output scaling final distance value
Tab. 32 Block of coherent parameters for the analogue output
9.9 Process data IN
Bit 15 14…6 5…3 2 1 0
Significance MSB
–
LSB
Process data Process Data Variable(PDV) SSC3 SSC2 SSC1
Data content Distance 10 bit PDV
(InA/InB)
OutC OutB OutA
Index 0x0028 0x0028
Sub-Index 1 2 3 4
Data type UInteger10 Boolean
Tab. 33 Process data IN
IO-Link interface description
43Festo — SOPA — 2020-04
