No. Action OUT Index Subind
ex
Data Remarks
1 Set first teach value (dis-
tance)
2 Select SSC channel A 0x003A 0x00 0x01 Select teach-in channel
1-OutA
B 0x003A 0x00 0x02 Select Teach-In channel
2-OutB
3 Send teach-in commands
(teach-in value)
0x0002 0x00 0x41 Default command
(0x0002 - 0x00) - Activate
SP1individual value
teach-in (0x41)
info Teach-In status 0x003B 0x04 1 -
taught-
in, 0 -
not
taught
TP1 for SP1
0x003B 0x02 1 -
taught-
in, 0 -
not
taught-
in
TP1 for SP2
Tab. 28 IO-Link teach-in for _|¯¯ mode, single-point mode, threshold value comparator
9.8 Block parameterisation
Block parameterisation can be used to prevent individual parameter values from being incompatible
with the values stored in the device. All parameters transmitted as a block will be simultaneously
accepted and activated.
9.8.1 Block parameterisation for Distance monitoring SSC1 (OutA)
Index Subindex Name
1 Set point SP1(SP)0x003C
2 Set point SP2
2 Switch point mode0x003D
3 Hysteresis (HY)
Tab. 29 Block of coherent OutA parameters
IO-Link interface description
42 Festo — SOPA — 2020-04
