9.10 Correction factors
Range [0 ... 2 bar]Unit
Gain Offset
mbar 0.122077763535 0
bar 0.000122077764 0
kPa 0.012207776354 0
MPa 0.000012207776 0
psi 0.001770591467 0
mmHg 0.091565891473 0
inch HG 0.003604956357 0
inch H
2
O 0.049010559727 0
kgf/cm" 0.000124482695 0
Tab. 34 Conversion factors for InC PDV, InC PDV Min, InC PDV Max and OutC switching point SP1, SP2
9.11 Diagnostics IO-Link
9.11.1 Status messages
Status Type Definition
0 Reserved Device is OK
1 Notification Service required
2 Warning Outside the specification
3 Error Functional check
4
–
Failure
Tab. 35 Status messages
9.11.2 Diagnostic levels
Diagnostic
level
Effect on display Effect on keys and out-
puts
Description
0
– –
Device is OK
1 Shows error no. in
show mode
–
No restriction in function yet but
operating parameters are deteriorat-
ing
IO-Link interface description
44 Festo — SOPA — 2020-04
