Festo SOPA - 6 Assembly; Measuring Nozzles

Both sets of bars are only active if the switching output at Pin 2 is assigned to the binary signal Out B.
The bars run synchronously if OutA and OutB have the same switching point.
If different switching points have been set, the bars are asynchronous to one another.
No.
1)
Bar graph Switches off if Description
9 Distance £ 1.6 x switching point
8 Distance £ 1.4 x switching point
7 Distance £ 1.2 x switching point
6
Display red
Distance £ 1.0 x switching point
Object outside the specified
switching range
2)
5 Distance £ 0.8 x switching point
4 Distance £ 0.6 x switching point
3 Distance £ 0.4 x switching point
2 Distance £ 0.2 x switching point
Object within the specified
switching range
2)
1
Display green
always on Sensor ready for operation
1) Segment number
2) The switching point of OutA and OutB is between segments 5 and 6
Tab. 8 Bar graph in the RUN mode
6 Assembly
6.1 Measuring Nozzles
Measuring Nozzle Geometry
NOTICE!
Damage due to Ingress of Foreign Matter or Liquids
In the event of an inappropriate measuring nozzle configuration or inappropriate routing of the com-
pressed air lines, foreign matter or liquids (e.g.condensation) can enter the product and cause a mal-
function or damage the product.
• Prevent the entry of foreign matter and liquids through design measures, forexample through a
suitable configuration of the measuring nozzles.
Assembly
17Festo — SOPA — 2020-04
