9.3 IO-Link default parameters
LengthIndex SubInde-
x
Name Value Access
1)
[Byte]
Format
0x0002 0 System Command è 9.4 IO-Link
default commands
W 1 UInter-
ger8
0x000C 0 Device Access Locks
è Tab. 24 Device
access blocking
bit-wise:
0 = unblocked
1 = blocked
R/W 2 Record
0x0020 0 Error Count 0 R 2 UInter-
ger16
0x0024 0 Device Status 0 R 1 UInter-
ger8
0x0025 0 Detailed Device
Status
è Tab. 35 Status
messages
R 24 Array of
3-byte
data
records
0x0028 0 Process Data Input è 9.9 Process data
IN
R 2 Record
1) R = read, R/W = read and write
Tab. 23 IO-Link default parameters
Bit no. Description
0 Block parameter write access (no effect)
1 Block data storage (no effect)
2 Block local parameterisation (EDIT and TEACH mode)
3 Block local user interface (SHOW, EDIT and TEACH mode)
Tab. 24 Device access blocking
IO-Link interface description
35Festo — SOPA — 2020-04
