9 IO-Link interface description
9.1 General information, IO-Link
Characteristic Specification
Protocol version Device V1.1
Profile Smart Sensor Profile (0x0001)
Identification and Diagnosis (0x4000)
Function classes Device Identification (0x8000)
Switching Sensor Channel (0x8001)
Process Data Variable (0x8002)
Device Diagnosis (0x8003)
Teach Channel (0x8004)
Extended Identification (0x8100)
Communication mode COM2 (38.4kbaud)
SIO-Mode support yes
Port class A
Process data length OUT 0byte
Process data length IN 2byte
Process data content IN Distance monitoring SSC1 (Switching Signal Channel 1)
Distance monitoring SSC2 (Switching Signal Channel 2)
Supply pressure monitoring SSC3 (Switching Signal Channel 3)
Distance 10bit PDV (Process Data Variable)
Service data IN supply pressure 14bit
Min. cycle time 3ms
Data storage required 0.5KB
Vendor ID 333
Device ID è Tab. 21 Device ID values
Tab. 20 General IO-Link specification
Device ID Order code
192 SOPA-PNLK-VB
193 SOPA-PNLK-A
Tab. 21 Device ID values
IO-Link interface description
33Festo — SOPA — 2020-04
