9.4 IO-Link default commands
Value Value
[dec] [hex]
Access
1)
Command Description
65 0x41 W SP1 Single Value Teach Determines the teach-in point
for switching point SP1.
128 0x80 W Device reset Warm start of the device.
129 0x81 W Application reset Application-specific parameters
are reset.
130 0x82 W Restore factory settings Reset the configuration and the
parameters to the original con-
dition (default)
160 0xA0 W Reset min. distance PDV (InA) Minimum InA-measurement
value is reset.
161 0xA1 W Reset max. distance PDV (InA) Maximum InA-measurement
value is reset.
164 0xA4 W Reset min. supply pressure PDV
(InC)
Minimum InC measured value is
reset.
165 0xA5 W Reset max. supply pressure PDV
(InC)
Maximum InC measured value is
reset.
1) W = write, - = no access
Tab. 25 Additional IO-Link default commands
9.5 Smart sensor profile parameters
LengthIndex SubInde-
x
Name Value Access
1)
[Byte]
Format
0 Profile Characterist-
ics
R 12 Array of
UIn-
teger16
1 0x0001: Smart
Sensor Profile
R 2
2
Device Profile ID
0x4000: Identifica-
tion and Diagnosis
R 2
3 Function Class ID 0x8001: Switching
Sensor Channel
R 2
0x000D
4 Function Class ID 0x8004: Teach Chan-
nel
R 2
UIn-
teger16
IO-Link interface description
