LengthIndex SubInde-
x
Name Value Access
1)
[Byte]
Format
0 PDInput Descriptor R 6 Array of
Octet-
String3
1 SSC1, SSC2, SSC3 0x01, 0x03, 0x00 R 3 Octet-
String3
0x000E
2 PDV 0x02, 0x0A, 0x06 R 3 Octet-
String3
0 - SSC1 (OutA),
default
1 - SSC1 (OutA)
0x003A 0 Teach-In Channel
2 - SSC2 (OutB)
R/W 1 UIn-
teger8
0 Teach-In Status 0 R 1 Record
1 Teach Flag TP2 for
SP2
R 1
2 Teach Flag TP1 for
SP2
R 1
3 Teach Flag TP2 for
SP1
R 1
4 Teach Flag TP1 for
SP1
not used
R 1
BooleanT
0x003B
5 Teach State 0 R 1 UIn-
teger4
SSC1, distance monitoring (OutA)
1 Set point SP1 (SP) 20 ... 300, default:
100
20x003C
2 Set point SP2 Not used, default: 0 2
UIn-
teger16
0 - normally open
(NO), standard
1 Switch point logic
1 - normally closed
contact (NC)
1
2 Switch point mode Not used, default:
132
1
UIn-
teger8
0x003D
3 Hysteresis (HY) 3 ... 20, default: 5
R/W
2 UIn-
teger16
IO-Link interface description
37Festo — SOPA — 2020-04
