Festo SOPA - IO-Link Teach-In

LengthIndex SubInde-
x
Name Value Access
1)
[Byte]
Format
5 = 15 min
6 = 30 min
7 = 60 min
0x01E8 0 Backlight (Eco-
Mode) or numerical
display (always
on/off or time to
switch off after last
key actuation)
8 = 90 min
R/W
0 - not blocked,
default
0x01EA 0 Lock code
³1 (blocked for local
parameter access)
R/W
0x2001 0 PDV (InA) process
value distance
3)
0 ... 2
10
- 1 R
0x2003 0 PDV (InC) process
value, supply pres-
sure monitoring
3)
0 ... 2
14
- 1 R
0x2005 0 InA Minimum detec-
tion value distance
(MIN)
3)
0 ... 2
10
- 1 R
0x2006 0 InA Maximum detec-
tion value distance
(MAX)
3)
0 ... 2
10
- 1 R
0x2009 0 InC minimal meas-
ured supply pres-
sure value
(MIN)
3)
0 ... 2
14
- 1 R
0x200A 0 InC maximal meas-
ured supply pres-
sure value
(MAX)
3)
0 ... 2
14
- 1 R
2 UIn-
teger16
1) R = read, R/W = read and write, –= no access
2) only for SOPA-PNLK-VB
3) volatile (non-permanent) parameter
Tab. 27
9.7 IO-Link teach-in
Overview
IO-Link teach-in is only available for OutA and OutB on this device, each with one value for the
threshold value comparator.
IO-Link interface description
40 Festo — SOPA — 2020-04
