15 Technical data
15.1 Technical data, general
General
Approvals RCM compliance mark
c UL us - Recognised (OL)
1)
1) type-specific èidentification on the product
Tab. 39 General
SOPA-… -C -M
Detected variable
–
Distance
Measuring principle
–
pneumatic
Sensing range [μm] 20…200
Operating pressure [MPa] 0.4…0.7
–
[psi] 60…105
–
[bar] 4…7
–
Supply pressure [MPa]
–
0.08…0.16
[psi]
–
11.6…23.2
[bar]
–
0.8…1.6
Nominal pressure [MPa] 0.5 0.12
[psi] 75 18
[bar] 5 1.2
Operating medium Compressed air in accordance with ISO 8573-1:2010 [7:4:4]
Temperature of medi-
um
[°C] 0…+50
Ambient temperature [°C] 0…+50
Tab. 40 Input signal/measuring element
SOPA-… -C -M
Repetition accuracy of switching point
– Sensing range
30μm…150μm
–
±2.5
– Sensing range
20μm…200μm
–
±5
Tab. 41 Output, general
Technical data
