34 FCP-75 Manual — P/N LS10147-003FK-E:A 3/17/2021
Control Panel Installation FIK-RA2000 Remote Annunciator Installation
Figure 4.23 Back Box Mounting Holes
2. Remove knockout holes as needed for wires. See Figure 4.11 for backbox knockout locations.
.
Figure 4.24 Back Box Knockout Locations
3. Wire the annunciator board to the main control panel. As described in Section 4.7.2.
Mounting Holes
Mounting Holes
Wire Knockouts
Wire Knockouts
Wire Knockouts
