Maintenance Instructions
22.3.11 Panda PMS 8.000 NE - 42 NE Manual.R05 - Kapitel/Chapter 6: Maintenance Instructions Seite/Page 111
Fig. 6.8.1.3-7: Press in ball bearingWith the other hand, put a screw wrench on the long nut, fasten
slowly.
Thus the ball bearing is pressed onto the shaft.
If necessary hold driving shaft with suitable wrench, to prevent
diesel engine from rotation simultaneously.
Press on ball bearing as far as possible.
(Tool Wrench SW13 and SW 22)
Sample Picture
Fig. 6.8.1.3-8: Hold up the driving shaftHold up the driving shaft.
Sample Picture
Fig. 6.8.1.3-9: Remove tools and markings
• Remove tools.
• Remove markings.
• Mount cooling disc (if existent).
• Mount presilencer and circuit points.
• Refill cooling water and vent cooling water circuit (see gene-
rator manual.
• Remove starting lock.
• Reconnect starter battery.
• Run generator 3 to 5 minutes.
• Mount casing.
Sample Picture
