The Panda Generator
Seite/Page 42 - Kaptitel/Chapter A: The Panda Generator 19.8.14
A.1.4 Left Side View
Fig. A.1.4-1: Left Side View
01. Water/cooled pre-silencer
02. Exhaust output
03. Return pipe expansion tank
04. Sound cover
