Water-cooled exhaust manifold
Fig. A.25: Water-cooled exhaust manifold
Compensator under heat isolation
This part is flexible by the internal
structure and compensates vibrations.
Fig. A.26: Compensator
Exhaust outlet
The silencer must be attached here.
Fig. A.27: Exhaust outlet
