The Panda Generator
Seite/Page 58 - Kaptitel/Chapter A: The Panda Generator 19.8.14
Thermo-switch at pre-silencer
At this point th coolant usually achieves its
highest value. From here it flows back into
the radiator.
Fig. A.40: Thermo-switch at silencer
Thermo-switch at the generator coil
1. Generator coil
2. Thermo-switch
3. Housing
Fig. A.41: Thermo-switch
Oil pressure switch at engine
Fig. A.42: Oil pressure switch
