I&J7000 Series Operating Manual
Section 5: Dispensing Parameters
Part # 561978B
Rev. H May 04
The retract function requires the following parameters:
RETRACT LENGTH – the distance to travel away from the line end point
RETRACT HEIGHT – the distance to rise as the tip moves away from the line end
RETRACT SPEED – the speed at which to move along the retract path
RETRACT TYPE – 1. NORMAL
2. SQUARE
3. FORWARD
4. CANCEL
- Normal means move back and up at an angle
- Square means move up first, then back – in a ‘square’ shape
- Forward means continue moving in the lne direction, up at an angle
- Cancel will cancel retract motion from the current memory address forward or until
the next retract instruction is found.
Retract values will be used for all lines from the current memory address forward until
another Retract instruction is found or the function is canceled.
