I&J7000 Series Operating Manual
Section 6: Point Type & Function Details
Part # 561978B
Rev. H May 04
4.7. Cycle Counter
When in run mode, the first line of the display shows the number of program cycles which
have run to completion for the current program number: [RUN MODE][X]
It is possible to reset this number by selecting MENU1, Utility Menu, Cycle Counter.
When prompted for the New Val:, press 0 and ENTER to reset the cycle counter.
It is also possible to cause an alarm to be generated after a fixed number of program
cycles. Select MENU1, Utility Menu, Cycle Counter. When prompted for the New Val:,
type the number of program cycles to complete before generating the alarm and press
ENTER.
In run mode, when the set number of program cycles has been completed, the display will
show Counter Full ! and the start button will be disabled. The machine must be powered
off and the Cycle Counter must be reset before the program can be run again. The
counter can also be reset using the following procedure:
With the power OFF, press and hold the START
button.
While holding the start button in, turn the power
on.
1. Reset Counter
2. Adjust Origin
Select:
Press 1 to reset the cycle counter to zero.
