FISNAR I&J7300 - I&J7200 A - Z Axis Parts List

I&J7000 Series Operating Manual
Section 8: Schematic and Parts List
Part # 561978B
Rev. H May 04
- Page 93 -
© 2003 I&J Fisnar Inc.
1.6. I&J7200A - Z Axis Parts List
No.
Part No.
Description
1
310400001
C Clip
2
310400006
Bearing
3
310308002
Timing Belt (ψ10H7 )
4
310150006
Idle Pulley
5
310311001
Motor
6
320308004
Timing Belt (ψ8H7 )
7
310102004
Z Fixing Plate
8
310303003
LM Guide
9
310100004
Optical Limit Switch Base
10
310309002
Timing Belt
11
310100002
Timing Belt Fixing Base
12
320230004
Timing Belt Fixing Plate
13
310210004
Z Sliding Plate
14
310400004
PVC Pad
15
310400005
Tension Spring
16
801000030
Optical Limit Switch (U Type)
17
310100001
Z Tooling Base
18
130140011
Spacer for Idle Pulley Shaft
19
800416003
SUS Nuts M4
20
800417009
SUS Spring Washer M4
21
800417001
SUS Flat Washer M3
22
800417002
SUS Flat Washer M4
23
800410058
Alloy Set Bolt M3x5
24
800410003
Alloy Hexagonal Socket Bolt M3x10
25
800410004
Alloy Hexagonal Socket Bolt M3x15
26
800410009
Alloy Hexagonal Socket Bolt M4x10
27
800410010
Alloy Hexagonal Socket Bolt M4x15
28
800415005
SUS Hexagonal Socket Bolt M4x10
