FISNAR I&J7300 - I&J7300 B - X;Y Base Parts List

I&J7000 Series Operating Manual
Section 8: Schematic and Parts List
Part # 561978B
Rev. H May 04
- Page 96 -
© 2003 I&J Fisnar Inc.
2.4. I&J7300B – X/Y Base Parts List
No.
Part No.
Description
1
801000228
X Motor (5 phase)
2
320308006
X/Y Timing Pulley
3
320400001
C Clip
4
320304001
Bearing
5
320150001
X/Y Idle Pulley
6
320105003
Y Base Plate
7
320303001
LM Guide
8
320309001
Timing Belt
9
320100003
Timing Belt Fixing Base
10
320230004
Timing Belt Fixing Plate
11
320230002
X/Y Optical Switch Trigger
12
320102008
Y Sliding Plate
13
801000031
Optical Limit Switch (L Type)
14
320105001
X Base Plate
15
320303001
LM Guide
16
320309001
Timing Belt
17
320102001
X Sliding Plate
18
320240003
Body Case
19
3L0250005
Control Panel
20
3L0250006
Body Bottom
21
320104001
X Side Plate
22
320105002
LH/RH Arm Plate
23
320400003
Padding
24
320104004
Working Table
25
130140011
Washer
26
800456003
SUS Nut M4
27
800457002
SUS Flat Washer
28
800457010
SUS Spring Washer M5
29
800455005
SUS Hexagonal Socket Bolt M4x10
30
800450058
Alloy Set Bolt M3x5
31
800450003
Alloy Hexagonal Socket Bolt M3x10
32
800450009
Alloy Hexagonal Socket Bolt M4x10
33
800450010
Alloy Hexagonal Socket Bolt M4x15
34
800450015
Alloy Hexagonal Socket Bolt M5x15
35
800460011
Screw M3x8
