I&J7000 Series Operating Manual
Section 6: Point Type & Function Details
Part # 561978B
Rev. H May 04
1. Point Menu
Below is a list of functions which are found under the ENTER key. These functions are
‘point-type’ functions, meaning that the values applied will occupy one memory address.
1.1. Dispense Dot
Registers the current XYZ location as a Dispense point for dot dispensing.
The dispense time and wait time must be set in a previous memory address by registering
a Point Dispense Setup instruction with the SETUP key.
The upward motion of the tip after dispensing can be controlled by registering a Dispense
End Setup instruction and / or a Z Clearance instruction in a previous memory address.
Dispense End Setup and Z Clearance instructions are registered using the SETUP key.
See also Section 6: 2.3 Point Dispense Setup, 2.4 Dispense End Setup and 2.5 Z
Clearance.
1.2. Line Start
Registers the current XYZ location as a Line Start point for line dispensing.
The line speed must be set in a previous memory address by registering a Speed
instruction using the SETUP key.
Dispense delay times used at Line Start and Line End points can be controlled by
registering a Line Dis. Setup instruction in a previous memory address. The Line Dis.
Setup instruction is registered by pressing the SETUP key.
See also Section 6: 2.1 Line Speed and 2.2 Line Dispense Setup.
