I&J7000 Series Operating Manual
Section 6: Point Type & Function Details
Part # 561978B
Rev. H May 04
1.17. Wait Point
Registers a Wait Point at the current X, Y, Z location. When executed, the tip will move to
that location and wait for the specified period of time.
1.18. Stop Point
Registers a Stop Point at the current X, Y, Z location. When executed, the tip will move to
that location and wait until the start button is pressed.
1.19. Home Point
Registers an instruction to ‘home’ all axis, sending them to the home position. See the
Setup Menu for instructions on changing the location of the home position.
1.20. Loop Address
Registers an instruction which will execute a group of instructions a user-specified number
of times.
When the Loop Address instruction is registered, the display will prompt for an Address
and Count.
Address is the memory address to jump to from the current address. This address must
be less than the current memory address.
Count is the number of times to execute the loop.
1.21. Dummy
Registers the current XYZ location as a Dummy point. The tip will simply pass through this
point. A dummy point is useful for avoiding obstacles on the work piece.
