FISNAR I&J7300 - I&J7200 A - X;Y Base Parts List

I&J7000 Series Operating Manual
Section 8: Schematic and Parts List
Part # 561978B
Rev. H May 04
- Page 91 -
© 2003 I&J Fisnar Inc.
1.4. I&J7200A - X/Y Base Parts List
No.
Part No.
Description
1
310311001
Motor
2
320308004
Timing Belt (ψ8H7 )
3
310103001
Y Base Plate
4
310303002
LM Guide (Y Axis)
5
310309001
Timing Belt
6
310100003
Timing Belt Fixing Base
7
320230004
Timing Belt Fixing Plate
8
310230003
Y Axis Limit Trigger
9
801000030
X/Y Optical Limit Switch (U Type)
10
310105001
X Base Plate
11
310303001
LM Guide (X Axis)
12
310102001
X Sliding Plate
13
310230002
X Axis Limit Trigger
14
310400004
PVC Padding
15
310210001
LH/RH Arm
16
310210003
LH/RH Arm Cover
17
310240003
Body Top
18
310210002
X Axis Back Panel Connecting Plate
19
310102002
Y Sliding Plate
20
3K0250003
Body Bottom
21
310250004
Control Panel
22
310102003
Working Table
23
130140011
Washer for Idle Pulley Shaft
24
310400001
C Clip for Shaft
25
310400006
Bearing
26
310308002
Idle Pulley (ψ10H7 )
27
310150005
Y Axis Idle Pulley Shaft
28
310150004
X Axis Idle Pulley Shaft
29
800460011
Screw M3x8
30
800457002
SUS Flat Washer M4
31
800457003
SUS Flat Washer M5
32
800457009
SUS Spring Washer M4
33
800450058
Alloy Set Bolt M3x5
34
800450003
Alloy Hexagonal Socket Bolt M3x10
35
800450009
Alloy Hexagonal Socket Bolt M4x10
36
800450010
Alloy Hexagonal Socket Bolt M4x15
37
800450014
Alloy Hexagonal Socket Bolt M5x10
38
800455002
SUS Hexagonal Socket Bolt M3x10
39
800450056
Alloy Hexagonal Socket Bolt (Round Head) M4x6
40
800450015
Alloy Hexagonal Socket Bolt M5x15
41
320400003
PVC Padding
42
800455005
SUS Hexagonal Socket Bolt M4x10
