2.2. Output Signals
Pin #
Description
1
NO
OUT #1
2
NC
OUT #1
3
COM
OUT #1
4
NO
OUT #2
5
NC
OUT #2
6
COM
OUT #2
7
NO
OUT #3
8
NC
OUT #3
9
COM
OUT #3
10
NO
OUT #4
11
NC
OUT #4
12
COM
OUT #4
13
NO
OUT #5
14
NC
OUT #5
15
COM
OUT #5
16
NO
OUT #6
17
NC
OUT #6
18
COM
OUT #6
19
NO
OUT #7
20
NC
OUT #7
21
COM
OUT #7
22
NO
OUT #8
23
NC
OUT #8
24
COM
OUT #8
25
GND
Output Relay: OMROM model G6E Subminiature, sensative SPDT relay
Resistive Load: 2A at 30 VDC
Life Expectancy: 500,000 operations min. at 2A, 30 VDC
IMPORTANT NOTE:
Output signals should be used only to drive external relays. Do not power external devices
through output signals directly. Electrical noise will damage the output signal relay.
