I&J7000 Series Operating Manual
Section 6: Point Type & Function Details
Part # 561978B
Rev. H May 04
1.3. Line Passing
Registers the current XYZ location as a Line Passing point. This is a location on the line
where the tip changes direction, such as at the corner on a rectangle.
1.4. Circle
Registers a circle with the circle center at the current XYZ location. To register a circle, jog
the tip to the circle center and press ENTER. The display will prompt for the circle
diameter. Type the diameter of the circle and press ENTER.
The line speed must be set in a previous memory address by registering a Speed
instruction using the SETUP key.
Dispense delay times used at the start of the circle and the end of the circle can be
controlled by registering a Line Dis. Setup instruction in a previous memory address. The
Line Dis. Setup instruction is registered by pressing the SETUP key.
See also Section 6: 2.1 Line Speed and 2.2 Line Dispense Setup.
The upward motion of the tip after dispensing can be controlled by registering a Dispense
End Setup instruction and / or a Z Clearance instruction in a previous memory address.
Dispense End Setup and Z Clearance instructions are registered using the SETUP key.
See also Section 6: 2.4 Dispense End Setup and 2.5 Z Clearance.
1.5. Arc
Registers the current XYZ location as an Arc point. Arc points are used to dispense
material along an arc or circular path.
See Section 4: Programming Example, for an example of the use of an arc point.
