FISNAR I&J7300 - Initial Output Status; Debug Speed; Jog Speed

I&J7000 Series Operating Manual
Section 6: Point Type & Function Details
Part # 561978B
Rev. H May 04
- Page 68 -
© 2003 I&J Fisnar Inc.
3.5. Initial Output Status
Initial Output Status sets the ON/OFF status of the output signals at the start of each
program cycle.
Initial Output Status value is the decimal representation of an 8 binary bit values
controlling the 8 output signals.
For example,
Decimal
Value
Output Status
(X = on, blank = OFF)
#1
#2
#3
#4
#5
#6
#7
#8
0
1
X
2
X
4
X
8
X
16
X
32
X
64
X
128
X
3.6. Debug Speed
Debug Speed allows the debug speed to be set. This speed is the speed at which the tip
will move when running in Debug mode. See also Section 6: 5.6 Debug Program
3.7. Jog Speed
The Jog Speed setting allows the user to select the jog speed for programming in Teach
mode. The Jog speed can be set to Low, Middle or High speed.
The default value is 2. High.
