4.4. Relocate Data
The Relocate Data function allows the position of a program to be corrected, including
correction for X offset, Y, offset and angle of rotation.
If, for example, the work piece fixture has been changed, the program position can be
adjusted automatically for the new fixture.
The Relocate Data function requires two reference points for the calculations. Choose two
point locations from you program which will be used as reference points. For example, to
relocate the program after a fixture change:
Instruction
Display Shows
1
In this example, memory address 3 is the first
reference point and memory address 4 is the
second reference point.
Jog the tip to the new, correct position for the first
reference point.
2
Press the MENU 1 key, then select Save Temp
Point to save the location. The display will
prompt for the temporary point number to save.
ADDR: 3 PROG:20
Save to Point(1-9):
3
Press 1 to save the first location in temporary
position #1.
4
Jog the tip to the new, correct position for the
second reference point.
5
Press the MENU 1 key, then select Save Temp
Point to save the location. The display will
prompt for the temporary point number to save.
ADDR: 4 PROG:20
Save to Point(1-9):
6
Press 2 to save the second location in temporary
position #2.
7
Press Menu 1, then 7. Utility Menu, and select
Relocate Program.
1.All Points
2.Some Points
SELECT:
