I&J7000 Series Operating Manual
Section 6: Point Type & Function Details
Part # 561978B
Rev. H May 04
The Expand Step & Repeat function is useful in situations where the user must edit
selected elements in a Step & Repeat group, although an expanded Step & Repeat
instruction will occupy more memory space than a an un-expanded instruction.
3.3. Program Name
Program Name allows the user to register a name for the current program. If a program
name is registered, it will appear on the display when that program is selected in Run
mode.
3.4. Z Axis Limit
Z axis Limit allows the user to limit the range of the Z axis.
Use the Z and Z keys to bring the Z axis to the lowest point the Z axis should be allow
to travel (the highest Z axis numeric value), then select Menu 1, 4. Z Axis Limit.
The Z axis range of motion will be limited to the current value.
