FISNAR I&J7300 - I&J7300 B - Z Axis Parts List

I&J7000 Series Operating Manual
Section 8: Schematic and Parts List
Part # 561978B
Rev. H May 04
- Page 98 -
© 2003 I&J Fisnar Inc.
2.6. I&J7300B – Z Axis Parts List
No.
Part No.
Description
1
801000228
Motor (5 Phase)
2
320308005
Timing Belt (ψ8H7)
3
320102006
Z Motor Base
4
320104003
Z Fixing Plate
5
320303002
LM Guide
6
320309002
Timing Belt
7
320102003
Z Worm Upper Fixing Plate
8
320102004
Z Sliding Plate
9
320112001
Z LM Guide/Sliding Plate Connector
10
320102005
Z Worm Lower Fixing Plate
11
320100002
Z Sliding Plate Enforcement Side Plate
12
320300001
Worm
13
320304002
Bearing
14
320307001
Worm Locking Nut
15
320304003
Z Supporting Bearing
16
320230003
Z Optical Switch Trigger
17
320306001
Tension Spring
18
320308007
Timing Pulley
19
130400001
Oil Nozzle(M5)
20
801000031
Optical Limit Switch (U Type)
21
320100001
Z Tooling Base
22
800416003
SUS Nut M4
23
800417001
SUS Flat Washer M3
24
800417003
SUS Flat Washer M4
25
800417006
SUS Flat Washer M5
26
800415002
SUS Flat Washer M10
27
800415005
SUS Hexagonal Socket Bolt M3x10
28
800415018
SUS Hexagonal Socket Bolt M4x10
29
800415058
SUS Flat Head Bolt (Philp) M4x10
30
800410003
Alloy Set Bolt M4x5
31
800410009
Alloy Hexagonal Socket Bolt M3x10
32
800410010
Alloy Hexagonal Socket Bolt M4x10
33
800410014
Alloy Hexagonal Socket Bolt M4x15
34
800410015
Alloy Hexagonal Socket Bolt M5x10
35
800410016
Alloy Hexagonal Socket Bolt M5x20
36
800410022
Alloy Hexagonal Socket Bolt M6x10
