3.1.5. Dispen.TM (Dispense Time)
To use group edit to increase all of the dispensing times (Point Dispense Setup) in
memory address range 1 – 200 by 15%:
Instruction
Display Shows
1
Press the MENU 1 key, then 1 to select Group
Edit. The display will prompt the user to enter the
starting memory address of the group to edit
(From) and the ending number of the group to
edit (To).
GROUP EDIT
FROM:1
TO:1
(1 <-> 1000)
2
Type 1 then press ENTER to register 1 in From.
Type 200 then press ENTER to register 200 in
To.
GROUP EDIT 1-200
1.Copy 4.Line SP
2.Delete 5.Dispen.TM
3.Move 6.Offset
3
The Group Edit menu will then appear, allowing
the user to select from which function to apply to
the range of points.
Press 5 to select Dispen.TM.
GROUP DISPENSE TM
Multiple Value:
4
The display will prompt the user to type the
Multiple Value to be applied to the dispense
times. For example, a value of 1.15 will increase
all dispense times by 15%. A value of 0.85 will
decrease all dispense times by 15%.
Type 1.15 and press ENTER to select a multiplier
of 1.15.
GROUP DISPENSE TM
Multiple Value:1.15
1.Yes 2.No
SELECT:
5
The display will now prompt the user to confirm
the change. Press 1 to select Yes.
All of the Point Dispense Setup instructions in the
select range of points will now be multiplied by
1.15.
