FISNAR I&J7300 - Model Specifications Comparison

I&J7000 Series Operating Manual
Section 7: Specifications
Part # 561978B
Rev. H May 04
- Page 83 -
© 2003 I&J Fisnar Inc.
3. System Specifications
I&J 7200A
I&J 7300B
I&J 7400B
Working Area
X / Y / Z (mm)
200 / 200 / 50
300 / 300 / 100
400 / 400 / 100
Load Worktable / Tool
7.0kg / 3.5kg
11.0kg / 6.0kg
11.0kg / 6.0kg
Maximum Speed
X&Y / Z (mm/sec)
500 / 250
800 / 320
800 / 320
Repeatability
+/- 0.02mm/ Axis
+/- 0.02mm/ Axis
+/- 0.02mm/ Axis
Resolution
0.01mm/Axis
0.01mm/Axis
0.01mm/Axis
Data Memory
64 MB
4000 points/program
100 programs
64 MB
4000 points/program
100 programs
64 MB
4000 points/program
100 programs
Data Storage
64 MB
Compact Flash
64 MB
Compact Flash
64 MB
Compact Flash
Processor
32 Bit
300 Mhz
32 Bit
300 Mhz
32 Bit
300 Mhz
Display
Teach Pendant LCD
Teach Pendant LCD
Teach Pendant LCD
Drive System /
Stepping Motor
3-Phase
5-Phase
5-Phase
Motion Control
PTP & CP
PTP & CP
PTP & CP
Linear / Circular
Interpolation
3 axes
3 axes
3 axes
Teaching Method
Teach Pendant
Teach Pendant
Teach Pendant
I/O Signals
8 Inputs / 8 Outputs
8 Inputs / 8 Outputs
8 Inputs / 8 Outputs
External Interface
RS232
RS232
RS232
Power Supply
Auto-switching:
AC95-132V 150W
AC180-250V 150W
Auto-switching:
AC95-132V 300W
AC180-250V 300W
Auto-switching:
AC95-132V 300W
AC180-250V 300W
Working Temperature
0 – 40 C
0 – 40 C
0 – 40 C
Relative Humidity
(no condensation)
20 – 90%
20 – 90%
20 – 90%
Dimensions
(WxDxH) (mm)
315 x 360 x 720
560 x 640 x 915
680 x 760 x 915
Weight
20 kg
50 kg
57 kg
