FISNAR I&J7300 - Offset

I&J7000 Series Operating Manual
Section 6: Point Type & Function Details
Part # 561978B
Rev. H May 04
- Page 65 -
© 2003 I&J Fisnar Inc.
3.1.6. Offset
The Offset function allows all XYZ locations in a program to be shifted in the X, Y, or Z axis
by a user-defined distance.
To use group edit to add 15 mm to all X axis values in memory address range 1 – 200:
Instruction
Display Shows
1
Press the MENU 1 key, then 1 to select Group
Edit. The display will prompt the user to enter the
starting memory address of the group to edit
(From) and the ending number of the group to
edit (To).
GROUP EDIT
FROM:1
TO:1
(1 <-> 1000)
2
Type 1 then press ENTER to register 1 in From.
Type 200 then press ENTER to register 200 in
To.
GROUP EDIT 1-200
1.Copy 4.Line SP
2.Delete 5.Dispen.TM
3.Move 6.Offset
3
The Group Edit menu will then appear, allowing
the user to select from which function to apply to
the range of points.
Press 6 to select Offset.
GROUP OFFSET
X Offset: mm
X Offset: mm
Z Offset: mm
4
The display will prompt the user to type the X, Y,
and Z offset amounts to be added to all points in
address range 1 – 200.
Type 15 and press ENTER to add 15 mm to the
X axis values. Press ENTER two more times to
leave the Y and Z offsets at zero.
GROUP OFFSET
1.Yes 2.No
SELECT:
5
The display will now prompt the user to confirm
the change. Press 1 to select Yes.
15 mm will be added to all of the X axis values in
the selected range.
