FLENDER B3 A Series - Ambient Temperature; Types; Table

Example code
The following is an example of the code printed in line 5 of the rating plate and explains the
meaning of the individual letters and numbers.
,QFRUSRUDWLRQ
6L]H
2XWSXWVKDIWYHUVLRQ
*HDUXQLWW\SH
WR
6ROLGVKDIW
6HOIDOLJQLQJV\VWHP
+ROORZVKDIWZLWKSDUDOOHONH\ZD\
+ROORZVKDIWIRUVKULQNGLVN
+ROORZVKDIWZLWKLQWHUQDOVSOLQHDFFRUGLQJWR',1b
1XPEHURIVWDJHV

%HYHOKHOLFDOJHDUXQLW
ZLWKVSOLWKRXVLQJ
6SHFLDOKRXVLQJ
%6
6
$
)
%
+
'
$
.
Further information
You can 󹪝nd additional information on the weights and the enveloping surface sound pressure
levels in chapters Weights (Page 125) and Enveloping surface sound pressure level (Page 125).
Further information about these technical data can be found in the separate data sheet and the
dimension drawings in the complete documentation for the gear unit.
B.2 Ambient temperature
Unless otherwise contractually agreed, the gear unit must not be exposed to any harmful
atmospheres or substances such as aggressive chemical products. By applying various suitable
measures, the gear unit can be used in the ambient temperature range extending from -40 °C
up to 60 °C. However, this must always be authorised by Flender and speci󹪝ed in the order text.
B.3 Types
The gear units are designed as 󹪞ange-mounted units (by shrink-󹪝tting of a coupling 󹪞ange) or
as shaft-mounted units for mounting on the machine shaft. A bell housing or bracket for
supporting the motor and coupling can be 󹪞ange-mounted at the input end.
Technical data
B.3 Types
