2.3 General information
Introduction
All work on the gear unit should be performed with care and only by quali󹪝ed personnel.
Symbols on the gear unit
The following symbols apply to the gear unit; some of which are found as coloured markings on
the gear unit:
Table 2-1 Symbols and markings
Points labelled on the gear unit Symbol Coloured markings
Earth connection point
Air relief point yellow
Oil 󹪝lling point yellow
Oil draining point white
Oil level indicator red
Oil level measurement red
Oil over󹪞ow
Connection point for vibration monitoring
Lubrication point red
Apply grease
Lifting eye
Eye bolt
Safety instructions
