Requirement
Check that everything has been delivered immediately upon receipt.
NOTICE
Damage to the gear unit due to corrosion
Exposing the gear unit to moisture can result in damage from corrosion.
Do not damage or open the packaging prematurely if the packaging is designed to preserve the
unit.
Procedure
To unpack and use the gear unit, proceed as follows:
1. Remove packaging and transport devices in accordance with regulations.
2. Perform a visual inspection for damage and accumulations of dirt.
3. Immediately report any damaged and/or missing parts to Customer Services.
4. Dispose of packaging material and transport devices in accordance with regulations.
5.3 Gear unit assembly
5.3.1 Foundation
Properties of the foundation
The foundation must have the following properties:
• Stability
• Designed for torsional rigidity
• Reaction forces from the gear unit must be braced
Requirements of the foundation
The foundation must meet the following requirements:
• Construct the foundation in such a way that it does not generate any resonance vibrations
and that it is isolated against the transmission of vibrations from adjacent foundations.
• Design the foundation according to the relevant weight and torque, taking into account the
forces acting on the gear unit.
Assembly
5.3 Gear unit assembly
Assembly and operating instructions A5051en
Edition 06/2020 63
