• Loads must not be suspended from the tip of a load hook
• Always place the products down on a level, non-slip and stable base
DANGER
Falling load
There is a risk of fatal injury from falling loads if these have not been securely attached to the
lifting equipment.
Never stand or sit under suspended loads. Do not exceed the load limits of the lifting
equipment.
Packaging
The gear unit is delivered fully assembled. Additional equipment is also delivered separately
packaged, as necessary.
The gear unit may be packed in various forms, depending on the size of the unit and method of
transport.
Please adhere to the symbols applied on the packaging.
7KLVZD\XS)UDJLOH
.HHS
GU\
.HHS
FRRO
&HQWUHRI
JUDYLW\
'RQRW
XVHKDQGKRRNV
$WWDFKKHUH
Figure 4-1 Transport symbols
4.3 Attachment points
Lifting eyes
Lifting eyes are tted to the gear unit to assist with its transportation during manufacture and
installation.
Carefully ensure that the angle of the vertical load at the gear units lifting eyes does not exceed
45°.
Sling swivel
Threads for screwing in transport lugs are provided on the gear unit to assist with its
transportation during manufacture and installation.
Application planning
4.3 Attachment points
Assembly and operating instructions A5051en
Edition 06/2020 53
