Figure 3-16 Fully assembled acceleration sensor (C), and the threaded connector (D) for variants 5A and
5B
Further information
Further information and a detailed illustration of the gear unit with attached sensors can be
found in the dimension drawing in the complete documentation for the gear unit.
Further information about the sensors can be found in the operating instructions for the sensors.
3.18 Speed encoder
Depending on the order specication, an incremental speed encoder can be tted.
Customers must establish the wiring and provide the evaluation unit required.
Description
3.18 Speed encoder
Assembly and operating instructions A5051en
Edition 06/2020 43
