KVOV KVOH KFOV
KZAU KDAU
B.4 Weights
The precise weights are specified in the dimension drawings in the complete documentation or
on the rating plate.
All weight specifications refer to units without oil filling or mounted components.
Refer to the following tables for the weights (approximate values, in kg) of the gear units:
Table B-1 Weights
Type Gear unit size
80 100 112 125 140 160 180 200 225 250
SEN 14 26 - 52 - 105 - 210 - 400
SZN - - 53 72 100 135 185 260 350 480
SZO - - 46 63 87 120 160 225 310 420
SZA - - 53 72 100 135 185 260 350 480
SDN - - - - - 150 205 285 390 540
SDO - - - - - 130 175 245 330 460
SDA - - - - - 150 205 285 390
Technical data
B.4 Weights
REDUREX Gear unit 5200en
118 Operating Instructions 03/2019
