2.3 General information
Introduction
All work on the gear unit should be performed with care and only by qualified personnel.
Symbols on the gear unit
The following symbols apply to the gear unit; some of which are found as coloured markings on
the gear unit:
Table 2-1 Symbols and markings
Points labelled on the gear unit Symbol Coloured markings
Earth connection point
Air relief point yellow
Oil filling point yellow
Oil draining point white
Oil level indicator red
Oil level measurement red
Oil overflow
Connection point for vibration monitoring
Lubrication point red
Apply grease
Lifting eye
Eye bolt
Do not unscrew
Safety instructions
2.3 General information
REDUREX Gear unit 5200en
14 Operating Instructions 03/2019
